Cisco HyperSwitch A100 Release Notes for Software Release 2.3

Permanent virtual circuit (PVC) establishment/deletion from the network management station (NMS) through the Simple Network Management Protocol (SNMP)
Traffic/performance management function
Diagnostics functions
Soft Reset
Additional/improved command line interface (CLI) commands
DS3/E3 support
Flash memory access protection
Enhanced SNMP MIB support

PVC Establishment/Deletion

Release 2.3 supports SNMP pvc establish and pvc delete from the NMS running CiscoView. The connection MIBs are proprietary. The procedure of how to establish/delete connections is included with CiscoView documentation.

Note CiscoView documentation is available on Cisco Connection Documentation CD-ROM or printed copies can be ordered.

Traffic Management/Accounting Functions:

The following traffic information can be retrieved by a console terminal or an NMS station.

Number of transmitted cells per connection
Number of received cells per connection
Number of transmitted cells per LINF
Number of received cells per LINF - Number of transmitted cells per LINF traffic class (Guaranteed Best Effort---GS/BE)
Number of received cells per LINF/traffic class (GS/BE)

The following performance information can be also retrieved by a console terminal and/or a NMS station:

Number of UPC violation cells per connection
Number of HEC errored cells per LINF
Number of Misdelivered cells per LINF

All these parameters are implemented by 32-bit roll-over counters. These counters will not be reset after the retrieval but can be reset via a CLI command (clear tcounter).

Related CLI commands

The following are related CLI commands:

show traffic

The show traffic command displays the line number and numbers of received (input) cells, transmitted (output) cells, misdelivered cells, Header Error Check (HEC) errored cells, and buffer overflow cells for each line. The contents of software-controlled, 32-bit counters are read out. (The counters can be reset with the clear tcounter command.)

Format:

A100> show traffic P1

Format explanation:

P1 Line number (0-15). Traffic and performance data of the specified LINF is displayed.

Command example:

A100> show traffic 8
Line Number : 8
Number of Received     Cell  :          0
Number of Transmitted  Cell  :          0

Number of Misdelivered Cell  :          0
Number of HEC Errored  Cell  :          0

show traffic type

Format:

A100> show traffic P1 type

Format explanation:

P1 Line number (0-15). Traffic data for different traffic types (GS, BE) on the specified LINF is displayed.

Command example:

A100> show traffic 8 type
Line Number : 8
                Received Cell Count        Transmitted Cell Count
CBR-GS Traffic                  0                           0
VBR-GS Traffic                  0                           0
UBR-BE Traffic              59917                       59920

clear tcounter

The clear tcounter command clears all traffic counters on all LINF cards.

Format:

A100> clear tcounter

Command example:

A100> clear tcounter
A100> show tr 8 type
Line Number : 8
                Received Cell Count        Transmitted Cell Count
CBR-GS Traffic                  0                           0
VBR-GS Traffic                  0                           0
UBR-BE Traffic                  0                           0

show pvc

The show pvc command displays all connection parameters set for the specified line number, VPI, and VCI.

Format:

A100> show pvc P1 P2 P3

Format explanation:

P1: Line number (0-15)

P2: VPI (0-4095). If P2 and P3 are omitted, all PVCs on the LINF specified by P1 are be displayed.

P3: VCI (0-4095). If P3 is omitted, all PVCs with the specified VPI established on the LINF specified by P1 are displayed. Otherwise the detailed information of the specified connection (uni, bi, or multicast) is displayed. Traffic and performance data of the specified LINF/VPI/VCI is displayed along with the connection data.

Output:

A100>show pvc 8
Bandwidth Available (Forward/Backward/Line Rate): 155.0 / 155.0 / 155.0 Mbps
Existing connections : 0 (Uni), 6 (Bi), 0 (Multipoint), 1 (Gateway)
LowLine LowVPI LowVCI  HiLine  HiVPI  HiVCI TrfType CONNECTION
    8       0       5    16       0       9 UBR-BE  Gateway
    8       0      50     2       0      50 VBR-GS  Bi
    8       0      60     2       0      60 UBR-BE  Bi
    8       0      61     2       0      61 UBR-BE  Bi
    8       3      60     2       3      60 UBR-BE  Bi
    8       3      61     2       3      61 UBR-BE  Bi
    8       3      62     2       3      62 UBR-BE  Bi
A100>show pvc 8 3
LowLine LowVPI LowVCI  HiLine  HiVPI  HiVCI TrfType CONNECTION
    8       3      60     2       3      60 UBR-BE  Bi
    8       3      61     2       3      61 UBR-BE  Bi
    8       3      62     2       3      62 UBR-BE  Bi

A100>show pvc 8 0 50
Connection Type       : Bi
Traffic Type          : VBR-GS
Low  Throughput       : 80Mbps
High Throughput       : 100Mbps
LowLine LowVPI LowVCI LowUP  LowCO   HiLine  HiVPI  HiVCI  HiUP   HiCO
    8       0     50   500  Discard     2       0     50   512  Discard

ATM Traffic :  LowIncoming  LowOutgoing   HighIncoming HighOutgoing
                        0            0              0            0


UPC Violation: LowIncoming  LowOutgoing   HighIncoming HighOutgoing
                        0            0              0            0

Diagnostics Functions:

Release 2.3 software supports the diagnostic capabilities for the following hardware components:

CPU/Processor card
Mother board (XATOM switching fabric)
Gateway PAD card
Line interface (LINF) card

While executing the diagnostic process, the corresponding online service of the hardware components is suspended. However, any individual LINF card can be checked without affecting the online service of the other LINF cards.

diagnosis

The diagnosis command displays diagnostic information.

Format:

A100> diagnosis P1 P2

Format explanation:

P1: One of the following:

cpu (CPU board diagnosis)

switch (XATOM/Mother board diagnosis)

gateway (Gateway PAD card diagnosis)

line (line interface card - LINF diagnosis)

all (Entire system diagnosis)

P2: Line number (specified when P1 = line)

The result of any diagnostics process is displayed on a console terminal or can be retrieved by entering the show alarm command.

Soft Reset

System soft reset from a console terminal and/or NMS station is supported. This CLI command is executed in an interactive manner.

Format:

reset

Command example:

A100# reset
Are you sure [Y or N]?

New and Improved CLI Commands

show pvc

The show pvc line and show pvc detail commands are combined into a single command. You can specify a line number, line number and VPI, or a line number and VPI and VCI. If only a line number is specified, all the connections on the specified LINF are displayed. If a line number and VPI are specified, all the connections with the specified VPI on the specified LINF are displayed.

Format:

A100> show pvc P1 (P2 (P3))

Format explanation:

P1: Line number (0-15)

P2: VPI (0-4095). If P2 and P3 are omitted, all PVCs on the LINF specified by P1 are be displayed.

P3: VCI (0-4095). If P3 is omitted, all PVCs with the specified VPI established on the line specified by P1 are displayed.

show svc

The display of the show svc command is improved.

Format:

A100> show svc P1

Format explanation:

P1: Line number (0-15)

pvc flush

The pvc flush command deletes all pvp and pvc connections associated with a specified LINF. However, the configuration data stored in the flash memory is not affected by executing this command. To change the contents of flash memory, use the save command. This CLI command is executed in an interactive manner.

Format:

A100# pvc flush P1

Format explanation:

P1: Line number (0-15)

pvc establish

The pvc establish commands allows the user to specify the throughput (data rate) parameters for both forward and backward directions.

Format:

pvc establish P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14

Format explanation:

P1: Connection type (uni, bi, or multicast)

P2: Traffic type (GS, BE)

P3: Low line number (0-15)

P4: Low VPI (0-4095)

P5:Low VCI (0 for VPC; 32-4095)

P6:Low UPVP (0-512)

P7: Low (forward) UPC enforcement option (through, discard)

P8: Low (forward) line (allocated) transmission rate (Mbps)

P9: High line number (0-15)

P10: High VPI (0-4095)

P11: High VCI (0 for VPC; 32-4095)

P12: High UPVP (0-512)

P13: High (backward) UPC enforcement option (through, discard)

P14: High (backward) line (allocated) transmission rate (Mbps)

Command example:

A100# pvc est 1 0 2 0 50 512 1 100 8 0 50 500 1 80
***Connection has been established.
Connection Type     : Bi
Traffic Type        : VBR-GS
Low  Throughput     : 100Mbps
High Throughput     : 80Mbps
LowLine LowVPI LowVCI LowUP  LowCO   HiLine  HiVPI  HiVCI  HiUP   HiCO
    2       0     50   512  Discard     8       0     50   500  Discard

A100-5# pvc est 1 2 2 3 60 66 0 0 8 3 60 66 0 0
***Connection has been established.
Connection Type     : Bi
Traffic Type        : UBR-BE
Low  Throughput     : 0Mbps
High Throughput     : 0Mbps
LowLine LowVPI LowVCI LowUP  LowCO   HiLine  HiVPI  HiVCI  HiUP   HiCO
    2       3     60    66  Through     8       3     60    66  Through

write erase (configuration erase)

The write erase command allows the administrator to completely erase any configuration data that may exist in the Flash memory and is only available in the privileged mode and executed in an interactive manner. The write erase command allows you to erase the entire configuration to start over.

Format:

A100# write erase

Command example:

A100# write erase
Are you sure [Y or N]?

save

The display output of the save command is modified as follows:

Command example:

A100# save
Please do NOT push reset button until the "save" is complete
#######[OK]

DS3/E3 Support

To support DS3 and E3 LINF cards, the set interface command is extended.

Format:

set interface P1 P2 P3 P4 P5 (P6 P7 P8)

Format explanation:

P1: Line number (0-15)

P2: UNI(0) - GFC + 8-bit VPI and 16-bit VCI

NNI(1): 16-bit VPI and 16-bit VCI

P3: Forum(0) - Unassigned cell is filled to adjust cell stream.

SS bit of the SONET Overhead = 10

ITU-T(1) - Idle cell is filled.

SS bit of the SDH Overhead = 11

P4: The number of valid VPI bits (0-8, default=4)

P5: The number of valid VCI bits (0-12, default=8)

P6: Line Build Out ->

0-255 feet(0)

255-450 feet(1)

P7: Cell delineation Method

PLCP - G.751(0)

Direct_Mapping - G.804(1)

P8: Payload_Not_Scrambled(0)

Payload_Scrambled(1)

P6 through P8 are for DS3/E3 LINF cards only and can be ignored for the other (PHY) types of LINF cards.

Flash Memory Access Protection

Release 2.3 software can recover from the reset button being pushed during the save operation. If the reset button is pushed during the save operation, the following message will be displayed on the NMS:

The configuration data was corrupted by pushing the reset button before the save is
complete!.

If your get this message, you need to reboot the software again using the initialize mode (i.e., set boot initialize because the configuration data stored in Flash memory was corrupted).

Enhanced SNMP MIB Support

The SNMP MIB support in Software Release 2.3 is enhanced over that available in Software Release 1.2.

Software Release 2.3 provides the following enhancements:

From the MIB-II (documented in RFC 1213):
- In the System Group, Software Release 2.3 provides read-only support for the following objects: sysDescr, sysObjectID, sysUpTime, and sysServices. Release 2.3 provides read-write support for the following objects: sysContact, sysName, and sysLocation.
- In the Interfaces Group, Software Release 2.3 provides read-only support for the following objects: ifDescr, ifType, ifPhysAddress, ifAdminStatus, ifOperStatus, ifLastChange, ifInOctets, ifInErrors, ifInUnknownProtos, ifOutOctets, and ifOutErrors.
- In the Simple Network Management Protocol (SNMP) Group, Software Release 2.3 provides read-only support for the following objects: snmpInPkts, snmpOutPkts, snmpInBadVersions, snmpInBadCommunityNames, snmpInBadCommunityUses, snmpInASNParseErrs, snmpInTotalReqVars, snmpInTotalSetVars, snmpInGetRequests, snmpInGetNexts, snmpInSetRequests, snmpInGetResponses, snmpInTraps, snmpOutTooBigs, snmpOutNoSuchNames, snmpOutBadValues, snmpOutGenErrs, snmpOutGetResponses, and snmpOutTraps. Release 2.3 provides read-write support for the snmpEnableAuthenTraps object.
From the AToM MIB (documented in RFC 1695), Software Release 2.3 provides read-only support for the following objects: atmInterfaceMaxVpcs, atmInterfaceMaxVccs, atmInterfaceConfVpcs, atmInterfaceConfVccs, atmInterfaceIlmiVpi, and atmInterfaceIlmiVci. Release 2.3 provides read-write support for the atmInterfaceMaxActiveVpiBits and atmInterfaceMaxActiveVciBits objects.
From the enterprise-specific A100 MIB:
- In the Device and Line Status Group, Software Release 2.3 provides read-only support for the following objects: nodeOperStatus, nodeIfConfPhysType, nodeIfConfRev, nodeIfConfStatus, nodeFanStatus, nodeSaveResult, and linfStatus. Release 2.3 provides read-write support for the following objects: nodeUpcWindowSize, nodeBestEffortBufferSize, nodeGuaranteedBufferSize, nodeBestEffortBufferThreshold, nodeGuaranteedBufferThreshold, nodeSaveConf, nodeReset, and linfConf.
- In the PVC Group, Software Release 2.3 provides read-only support for the following objects: connPvcIndexNext, connPvcIndexEnable, connPvcIndex, connPvcTopology, connPvcTrafficType, connPvcLowIfIndex, connPvcLowVPI, connPvcLowVCI, connPvcLowUpcParam, connPvcLowUpc, connPvcLowThroughput, connPvcHighIfIndex, connPvcHighVPI, connPvcHighVCI, connPvcHighUpcParam, connPvcHighUpc, connPvcHighThroughput, connPvcLowInCells, connPvcHighOutCells, connPvcLowOutCells, connPvcLowUpcViolatedCells, connPvcHighUpcViolatedCells, connPvcRowStatus, and connPvcCause.
- In the Per-Interface Performance Counters Group, Software Release 2.3 provides read-only support for the following objects: perfIfHecErrors, perfIfMisDelivdCells, perfIfOverFlowCells, perfIfInCBRCells, perfIfOutCBRCells, perfIfInVBRCells, perfIfOutVBRCells, perfIfInUBRCells, and perfIfOutUBRCells.

To obtain a copy of the A100 MIB using FTP, follow these steps:

Step 1 On your system, enter the ftp ftp.cisco.com command.

Step 2 Log in with the username anonymous.

Step 3 Enter your e-mail address when prompted for the password. (For example,


someone@xyz.com

Step 4 Enter the cd /ftp/pub/mibs command to change to the directory where the A100 MIB is stored.

Step 5 Enter the get LS100-R2-MIB.my command to transfer a copy of the A100 MIB to your system.

Step 6 Enter quit to end the FTP session.
