The Cisco 12000 series is the newest addition to the company's next generation of Internet routing products and is the premier platform for
Routers in the Cisco 12000 series are targeted at scaling Internet and enterprise backbones to speeds of 2.4 Gbps (OC-48) and beyond. The Cisco 12000 series provides the following features:
The GSR series includes three models: the Cisco 12004, 12008, and 12012.
The Cisco 12012 provides 12 slots and supports core network sites, where OC-3/STM-1 and OC-12/STM-4 interfaces are required, and the highest possible port density is necessary.
Routers in the Cisco 12000 series complement Cisco's existing Internet routers, specifically those in the Cisco 7500 series. (Cisco 7500 series routers are optimized to handle backbones built around DS-3/E-3 (45/34 Mbps) and OC-3/SONET/SDH (155 Mbps) facilities.) They also complement Cisco's ATM product line by offering an OC-12 ATM interface that enables Cisco 12000 series to be interconnected across an ATM network.
Table 7-1 lists the features and benefits available with the Cisco 12000 series routers.
| Feature | Benefits |
|---|---|
| Scalable performance
Wide range in switching capacity | Enables customers to dramatically expand backbone capacity within a single product family, avoiding the expensive tear-outs often needed for products not able to scale beyond OC-12/STM-4 rates. |
| Scalable network services | QoS/CoS mechanisms enable traffic engineering to increase network utilization and provide the basis for offering differential class of service models and a more profitable operating environment. |
Carrier class availability:
|
Ensures maximum uptime and minimum disruption of user traffic. |
| Integration with SONET/SDH transport network | Enables SONET/SDH resiliency capabilities to be extended to the Cisco 12000. |
| Cisco IOS software | Delivers scalable and service-rich software, providing high-performance Layer 3 queuing and traffic engineering capabilities to support IP QoS offerings. |
The Cisco 12000 series has the following standard features:
This section provides helpful information for planning your Cisco 12000 and chassis configuration. The Cisco 12012 supports 12 slots and the Cisco 12008 supports 8 slots. Either one or two of the slots are used for gigabit route processors, depending upon whether redundancy is required. In the Cisco 12012, 11 slots are available for a variety of fully hot-swappable line cards. Seven such slots are available in the Cisco 12008, and three in the Cisco 12004.
Cisco 12000 Series chassis slots are universal and can be populated with any combination of GRPs and line cards. Table 7-2 shows one possible configuration.
| Slot Number | Cisco 12012 | Cisco 12008 | Cisco 12004 |
|---|---|---|---|
| 0 | GRP | GRP | GRP |
| 1 | Redundant GRP1 (if required) or line card | Redundant GRP1 (if required) or line card | Redundant GRP1 (if required) or line card |
| 2 - 3 | Line card | Line card | Line card |
| 4 - 7 | Line card | Line card | N/A |
| 8 - 11 | Line card | N/A | N/A |
At the heart of the GSR is a multigigabit crossbar switching fabric that provides synchronized gigabit-speed interconnections for all of the other cards in the system. The switching fabric for the Cisco 12012 and 12008 consists of up to four switching cards, supplemented by a fifth card that provides 1:4 or 1:1 redundancy. The Cisco 12004 uses one 4-port switch card rather than the switching fabric used by the Cisco 12008 and 12012. The switching cards for the Cisco 12008 and 12012 are not interchangeable. Table 7-3 shows the valid configuration for the switching fabric.
The switch fabric for the 12012 and 12008 consists of two different type of assemblies: the Clock/Scheduler Controller (CSC) and the Switch Fabric (SFC). As the name implies, the CSC contains the switch fabric, but also includes the system clock and fabric scheduler. The SFC contains the switch fabric only. The 12004 fabric consists of a CSC assembly only, while GRPs and line cards are interchangeable across all Cisco 12000 models. The CSC and SFC assemblies are unique to each chassis type and are therefore, not interchangeable.
| Bandwidth Requirement per Slot | Number of CSCs | Number of SFCs | Raw Transmission Rate per Slot |
|---|---|---|---|
| OC-12/STM-4 | 1 | 0 | 1.25 Gbps |
| Redundant OC-12/STM-4 | 2 | 0 | 1.25 Gbps |
| OC-48/STM-16 | 1 | 3 | 5 Gbps1 |
| Redundant OC-48/STM-16 | 2 | 3 | 5 Gbps1 |
Redundancy in all key system components (processors, switch fabric, line cards, cooling, and power) minimizes possible network disruption if a failure occurs. Table 7-4 shows the valid redundancy options for each GSR product.
| System Element | Cisco 12012 | Cisco 12008 | Cisco 12004 |
|---|---|---|---|
| Switch cards | Yes | Yes | No |
| GRP | Yes | Yes1 | Yes1 |
| Line cards (APS) | Yes | Yes | Yes |
| Fans | Yes | Yes | No |
| Power supplies | Yes | Yes | Yes |
| Dimension or Specification | Cisco 12004 | Cisco 12008 | Cisco 12012 |
|---|---|---|---|
| Height | 14.0 in. (35.6 cm) | 24.85 in. (63.1 cm) | 56.0 in. (142.2 cm) |
| Width | 17.3 in. (43.9 cm) | 17.4 in. (44.2 cm) | 17.3 in. (43.9 cm) |
| Depth | 19.5 in. (49.5 cm) | 21.2 in. (53.8 cm) | 21.0 in. (53.3 cm) |
| Weight (maximum) | 123 lb (55.8 kg) | 187 lb (84.9 kg) | 380 lb (172.5 kg) |
| Shipping weight | 150 lb (68.1 kg) | 220 lb (100 kg) | 492 lb (223.4 kg) |
| Shipping dimensions | |||
| Height | TBD | 35.5 in (90.2 cm) | 67.0 in. (170.2 cm) |
| Width | TBD | 25.0 in (63.5 cm) | 24.88 in. (63.2 cm) |
| Depth | TBD | 39.5 in (100.3 cm) | 39.39 in. (100 cm) |
| Requirement Category | Cisco 12004 | Cisco 12008 | Cisco 12012 |
|---|---|---|---|
| DC Input Voltage | -48 to -60 VDC | -48 to -60 VDC | -48 to -60 VDC |
| DC Input Current | 16.9 A maximum at -48 VDC
13.5 A maximum at -60 VDC | 33.75A maximum at -48 VDC
27A maximum at -60 VDC | 37.1A maximum at -48 VDC
29.7A maximum at -60 VDC |
| AC Input Voltage | 100 to 240 VAC (50 to 60 Hz) | 200 to 240 VAC (50 to 60 Hz) | 200 to 240 VAC (50 to 60 Hz) |
| AC Input Current | 11.5A maximum at 100 VAC
5.5A maximum at 240 VAC | 10A maximum at 200 VAC
8.3A maximum at 240 VAC | 11.2A maximum at 240 VAC
4.7A maximum at 240 VAC |
| Power Supply Configurations1 | DC: 1 min, 2 for redundancy
AC: 1 min, 2 for redundancy | DC: 1 min, 2 for redundancy
AC: 1 min, 2 for redundancy | DC: 1 min, 2 for redundancy
AC: 2 min, 3 or 4 for redundancy (1:2 or 1:1) |
| Input VA | 810 maximum (DC input)
1320 maximum (AC input) | 1620 maximum (DC Input)
2000 maximum (AC Input) | 2259 maximum (DC Input) |
| Output Watts | 775 maximum | 1560 maximum | 1794 maximum |
| Heat Dissipation | DC: 810W (2765 Btus/hr)
AC: 1320W (4506 Btus/hr) | DC: 1620W (5530 Btus/hr)
AC: 2000W (6828 Btus/hr) | DC: 2259W (7712 Btus/hr) |
| Specification Category | Value |
|---|---|
| Temperature | Nonoperating: -40° to 149°F (-40° to 65°C)
Operating: 32° to 104°F (0° to 40°C) |
| Relative Humidity (relative, noncondensing) | Nonoperating: 5% to 95%
Operating: 10 to 90% |
| Vibration | Nonoperating: 5 to 200 Hz, 1 g (1 oct/min)
200 to 500 Hz, 2 g (1 oct/min) Operating: 5 to 200 Hz, 0.5 g (1 oct/min) |
The system software is based on IOS Version 11.2, but it has been optimized to support IP only. A software license is required for each Cisco 12000 series system. The license must accompany each system and chassis purchase, and is tied to the Cisco 12000 chassis serial number. If you are ordering only GSR spares, you need not order a software license.
Routing Protocols | Interior: RIP, OSPF, IS-IS, ISO/CLNP, EIGRP, EGP Exterior: BGP |
|---|---|
| Routed Protocols | TCP/IP, UDP/IP |
| BGP4 Support |
|
|
Management | SNMP, Telnet, MIB II |
There are 2 configurable memory types on the GRP; Flash (PCMCIA) and DRAM used to hold system software, routing table, etc. Default GRP memory is 20 MB PCMCIA flash, and 64MB DRAM, expandable to 256MB.
There are 2 configurable memory types on each of the Cisco 12000 line cards; packet memory (buffers) and route table memory. Default route table memory is 32 MB and is expandable to 256 MB. Default packet memory can be expanded to 128MB (64 MB Tx, 64 MB Rx).
Use the following steps to make up your order for a router in the GSR series:
There no special support or service requirements for the GSR series. You can obtain technical support from the Technical Assistance Center (TAC), and SmartNet contracts are available.
| Description | Product Number |
|---|---|
| Cisco 12008 GSR, 10 Gbps; 1 GRP, 1 CSC, 1 DC | GSR 8/10 |
| 256-MB GRP and LC program/route memory (2 x 128 MB) | MEM-GRP/LC-256 |
| Cisco 12008 GSR redundant DC supplies (2 DC supplies) | PWR-GSR8-DC/2 |
| IP IOS | SFGSR-11.2.9 |
| Cisco 12008 GSR scheduler/fabric/alarm | GSR8-CSC/ALRM= |
| 1 port OC-12/STM-4 ATM line card, multi-mode | LC-1OC12/ATM-MM= |
| 256-MB GRP and LC program/route memory (2 x 128 MB) | MEM-GRP/LC-256 |
| Line card buffer memory 64 MB/64 MB (Tx/Rx) | MEM-LC-PKT-128 |
| Description | Product Number |
|---|---|
| Cisco 12000 Base Systems | |
| Cisco 12012 Gigabit Switch Router, 15 Gbps;
1 GRP, 1 CSC, power supply (2 AC or 1 DC) | GSR12/15 |
| Cisco 12008 GSR, 10 Gbps; 1 GRP, 1 CSC-GSR8, 1 DC | GSR8/10 |
| Redundant Packages and System Upgrades | |
| Cisco 12012 redundant upgrade; 1 GRP, 1 CSC, 1 DC | GSR12-RED= |
| Cisco 12008 redundant upgrade 1 GRP, 1 CSC, 1 DC | GSR8-RED= |
| GSR Processors | |
| GSR Route Processor, 64 MB DRAM (default) | GRP |
| Switch Fabric/Clock Schedulers | |
Cisco 12012 Cisco 12012 GSR scheduler/fabric Cisco 12012 GSR redundant scheduler/fabric Cisco 12012 GSR switch fabric |
GSR12-CSC GSR12-CSC/R GSR12-SFC |
Cisco 12008 Cisco 12008 CSC/ALRM Cisco 12008 CSC/ALRM spare Cisco 12008 SFC Cisco 12008 SFC spare |
GSR8-CSC/ALRM GSR8-CSC/ALRM= GSR8-SFC GSR8-SFC= |
| Line Cards | |
Packet over SONET/SDH Quad-OC3c/SDH 4 port OC-3/STM-1 Packet over SONET/SDH line card, single-mode 4 port OC-3/STM-1 Packet over SONET/SDH line card, multimode |
LC-4OC3/POS-SM LC-4OC3/POS-MM |
Packet over SONET/SDH Single OC12c/SDH 1 port OC-12/STM-4 Packet over SONET/SDH line card, single-mode 1 port OC-12/STM-4 Packet over SONET/SDH line card, multimode |
LC-1OC12/POS-SM LC-1OC12/POS-MM |
ATM Single OC12 1 port OC-12/STM-4 ATM line card, single-mode 1 port OC-12/STM-4 ATM line card, multimode |
LC-1OC12/ATM-SM LC-1OC12/ATM-MM |
GSR System Software Cisco 12000 series GSR Base System Software License Cisco 12000 series GSR Base System Software License Spare |
SFGSRZ-11.2.9G SWGSRZ-11.2.9G= |
GSRP and Line Card Memory Options/Upgrades 32 MB LC program/route memory (1 x 32 MB) 64 MB GRP and LC program/route memory (1 x 64 MB) 128 MB GRP and LC program/route memory (1 x 128 MB) 256 MB GRP and LC program/route memory (2 x 128 MB) |
MEM-LC-32 MEM-GRP/LC-64 MEM-GRP/LC-128 MEM-GRP/LC-256 |
Packet Memory Line card buffer memory, 16 MB/16 MB (Tx/Rx) Line card buffer memory, 32 MB/32 MB (Tx/Rx) Line card buffer memory, 64 MB/64 MB (Tx/Rx) |
MEM-LC-PKT-32 MEM-LC-PKT-64 MEM-LC-PKT-128 |
| Power Supply Options | |
Cisco 12012 GSR Power Supply Options Cisco 12012 GSR DC supply Cisco 12012 GSR redundant DC supplies (2 DC supplies) Cisco 12012 GSR AC supply option (2 AC supplies) Cisco 12012 GSR Redundant AC supplies (4 AC supplies) |
PWR-GSR12-DC PWR-GSR12-DC/2 PWR-GSR12-AC/2 PWR-GSR12-AC/4 |
Cisco 12008 GSR Power Supply Options Cisco 12008 DC Cisco 12008 redundant DC Cisco 12008 DC spare Cisco 12008 AC Cisco 12008 AC spare Cisco 12008 Redundant AC |
PWR-GSR8-DC PWR-GSR8-DC/2 PWR-GSR8-DC= PWR-GSR8-AC PWR-GSR8-AC= PWR-GSR8-AC/2 |
| Power Supply Cords | |
Cisco 12012 GSR Power Cords Cisco 12012 GSR AC power supply cord, US Cisco 12012 GSR AC power supply cord, Australia Cisco 12012 GSR AC power supply cord, Europe Cisco 12012 GSR AC power supply cord, Italy Cisco 12012 GSR AC power supply cord, UK Cisco 12008 AC power cord, US Cisco 12008 AC power cord, Australia Cisco 12008 AC power cord, Europe Cisco 12008 AC power cord, Italy Cisco 12008 AC power cord, UK Cisco 12008 AC power cord spare, US Cisco 12008 AC power cord spare, Australia Cisco 12008 AC power cord spare, Europe Cisco 12008 AC power cord spare, Italy Cisco 12008 AC power cord spare, UK |
CAB-GSR12-US CAB-GSR12-AU CAB-GSR12-EU CAB-GSR12-IT CAB-GSR12-UK CAB-GSR8-US CAB-GSR8-AU CAB-GSR8-EU CAB-GSR8-IT CAB-GSR8-UK CAB-GSR8-US= CAB-GSR8-AU= CAB-GSR8-EU= CAB-GSR8-IT= CAB-GSR8-UK= |
| System Accessories and Spares | |
| Cisco 12012
Cisco 12012 GSR blower assembly spare Cisco 12012 GSR Card Cage assembly spare Cisco 12012 GSR Alarm Card Cisco 12012 GSR shipping container spare Cisco 12012 GSR chassis cable management kit spare Cisco 12012 GSR Air filter spare Cisco 12012 GSR Top Blower Plastic Cover Cisco 12012 GSR Bottom Blower Plastic Cover Cisco 12012 GSR DC Power Supply Plastic Cover Cisco 12012 GSR Power Supply Blank Cover |
GSR12-BLOWER= GSR12-CARDCAGE= GSR12-ALRM= PKG-GSR12= ACS-GSR12-CCBLM= ACS-GSR12-FLTR= ACS-GSR12-TOPCVER= ACS-GSR12-BTMCVER= ACS-GSR12-PWRCVR= MAS-GSR12-PWRBLNK= |
| Cisco 12008
Cisco 12008 GSR System blower assy spare Cisco 12008 GSR Pwr Supply blower assy spare Cisco 12008 GSR Chassis assy spare Cisco 12008 GSR shipping container spare Cisco 12008 GSR System Air Filter spare Cisco 12008 GSR rack mount kit spare Cisco 12008 GSR chassis cable management kit spare Cisco 12008 GSR Power Supply Blank Cover |
GSR8-SYSBLOWER= GSR8-PWRBLOWER= CHAS-GSR8= PKG-GSR8= ACS-GSR8-SYSFTR= ACS-GSR8-RMK= ACS-GSR8-CCBLM= MAS-GSR8-PWRBLNK= |
| Description | Product Number |
| Regulatory Compliance and Safety Information for the Cisco 12000 Series Gigabit Switch Router | 78-4347-01 |
| Cisco 12008 Installation and Configuration Guide | 78-4953-01 |
| Cisco 12008 AC Input Power Supply Replacement Instructions | 78-4954-01 |
| Cisco 12008 DC Input Power Supply Replacement Instructions | 78-4955-01 |
| Cisco 12000 Memory Replacement Instructions | 78-4338-02 |
| Cisco 12000 Route Processor Installation and Configuration | 78-4339-02 |
| Cisco 12008 Switch Card Replacement Instructions | 78-4956-01 |
| Cisco 12008 Fan Tray Replacement Instructions | 78-4957-01 |
| Cable-Management System Replacement Instructions | 78-4958-01 |
| Quad OC-3c/STM-1 Packet Over-SONET Line Card Installation and Configuration | 78-4333-02 |
| OC-12c/STM-4 Packet Over-SONET Line Card Installation and Configuration | 78-4341-02 |
| Asynchronous Transfer Mode Line Card Installation and Configuration | 78-4344-02 |
| Cisco 12008 Packing - Unpacking Instructions | 78-4960-02 |
|
|
