Cisco IOS Release 11.1 CA Release Note and Update to Configuration Guides and Command References
October 7, 1996
This document describes the features and caveats for Cisco Internetwork Operating System (Cisco IOS) Release 11.1 CA, up to and including Release 11.1(6)CA. Release 11.1(6)CA is a platform-specific software release that supports new features for the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers not available in Cisco IOS Release 11.1(6). This document supplements the Cisco IOS Release 11.1 documentation set with new and changed commands that support the new features in Release 11.1(6)CA.
This document will be updated as additional releases of Release 11.1 CA are made available to support new hardware and software features.
This document is divided into the following sections:
Use this document in conjunction with the Release Notes for Cisco IOS Release 11.1 and the Cisco IOS Release 11.1 configuration guide and command reference publications, specifically the Configuration Fundamentals Configuration Guide and Configuration Fundamentals Command Reference.
The release note portion of this document describes the platforms supported, packaging, boot ROM requirements, memory requirements, features, and caveats for Cisco IOS Release 11.1(6)CA.
Cisco IOS Release 11.1(6)CA supports the following platforms:
Refer to the Release Notes for Cisco IOS Release 11.1 publication for a summary of the LAN interfaces supported on each platform and the WAN data rates and interfaces supported on each platform.
The following feature sets are available in Release 11.1 CA for the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers. Refer to Release Notes for Cisco IOS Release 11.1 for a complete list of the features provided in these sets.
For the Cisco 7000 series routers with RSP7000 and Cisco 7500 series routers:
For the Cisco 7200 series routers:
The Cisco 7200 series requires a boot image of level 11.1(472), 11.1(5a), or later.
The VIP2 requires a boot image of level 11.1(472), 11.1(5a), or later.
Refer to the Release Notes for Cisco IOS Release 11.1 publication for the memory requirements for feature sets available in Release 11.1(6)CA.
New Features in Release 11.1(6)CA
The following new features have been added to Release 11.1(6)CA:
Refer to the Release Notes for Cisco IOS Release 11.1 publication for a list of the caveats that apply to Release 11.1(6). The caveats that apply to Cisco IOS Release 11.1(6) apply to Release 11.1(6)CA. Release 11.1(6)CA has no specific caveats for the new features in this software release.
If you have an account on CCO, you can view additional caveats using the bug search tools in the Bug Toolkit, such as the Bug Navigator.
Update to Configuration Guides
The information in the sections below supplements the Configuration Fundamentals Configuration Guide. Pointers to sections and page numbers are shown in italic typeface.
On page 194 of the "Configuring Interfaces" chapter of the Cisco IOS Release 11.1 Configuration Fundamentals Configuration Guide, add the following new "Enable Full-Duplex" section after the "Preallocate Buffers for Bursty FDDI Traffic" section:
To enable full-duplex mode on the FDDI full-duplex, single mode port adapter (PA-F/FD-SM) and FDDI full-duplex, multimode port adapter (PA-F/FD-MM) on the Cisco 7000 series routers with RSP7000 and the Cisco 7500 series routers, perform the following task in interface configuration mode:
| Task | Command |
|---|---|
| Enable full-duplex on the FDDI interface of the PA-F/FD-SM and PA-F/FD-MM port adapter. | fddi full-duplex |
On page 215 of the "Configuring Interfaces" chapter of the Cisco IOS Release 11.1 Configuration Fundamentals Configuration Guide, replace the "Configure Compression of PPP Data" section with the section shown below:
Configure Compression of PPP Data
You can configure point-to-point compression on serial interfaces that use PPP encapsulation. Compression reduces the size of a PPP frame via lossless data compression. PPP encapsulations support both predictor and Stacker compression algorithms.
If the majority of your traffic is already compressed files, do not use compression.
When you configure Stacker compression on the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers, there are three methods of compression. Specifying the compress stac command with no options causes the router to use the fastest available compression method:
Using hardware compression in the CSA frees the router's main processor for other tasks. You can also configure the router to use the VIP2 to perform compression by using the distributed option, or to use the router's main processor by using the software option. If the VIP2 is not available, compression is performed in the router's main processor.
When compression is performed in software installed in the router's main processor, it might significantly affect system performance. Cisco recommends that you disable compression in the router's main processor if the router CPU load exceeds 40 percent. To display the CPU load, use the show process cpu EXEC command.
To configure compression over PPP, perform the following tasks in interface configuration mode:
| Task | Command |
|---|---|
| |
encapsulation ppp |
| |
compress {predictor | stac}
or compress {predictor | stac [distributed | software]} (Cisco 7000 series routers with RSP7000 and Cisco 7500 series routers) or compress {predictor | stac [software]} (Cisco 7200 series routers) |
On page 217 of the "Configuring Interfaces" chapter of the Cisco IOS Release 11.1 Configuration Fundamentals Configuration Guide, replace the "Use the NRZ Line-Coding Format" section with the section shown below:
Use the NRZI Line-Coding Format
All FSIP interface types on the Cisco 7000 and the PA-8T synchronous serial port adapter on the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers support nonreturn-to-zero (NRZ) and nonreturn-to-zero inverted (NRZI) format. This is a line-coding format that is required for serial connections in some environments. NRZ encoding is most common. NRZI encoding is used primarily with EIA/TIA232 connections in IBM environments.
The default configuration for all serial interfaces is NRZ format. The default is no nrzi-encoding. To enable NRZI format, complete the following task in interface configuration mode:
| Task | Command |
|---|---|
| Enable NRZI encoding format. | nrzi-encoding
or nrzi-encoding [mark] (Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers) |
On page 218 of the "Configuring Interfaces" chapter of the Cisco IOS Release 11.1 Configuration Fundamentals Configuration Guide, replace the "Invert the Transmit Clock Signal" section with the section shown below:
Invert the Transmit Clock Signal
Systems that use long cables or cables that are not transmitting the TxC signal (transmit echoed clock line, also known as TXCE or SCTE.clock) can experience high error rates when operating at the higher transmission speeds. For example, if the interface on the PA-8T synchronous serial port adapter is reporting a high number of error packets, a phase shift might be the problem. Inverting the clock signal may correct this shift. To invert the clock signal, complete the following task in interface configuration mode:
| Task | Command |
|---|---|
| Invert the clock signal on an interface. | invert txclock |
On page 218 of the "Configuring Interfaces" chapter of the Cisco IOS Release 11.1 Configuration Fundamentals Configuration Guide, add the following new "Invert the Data" section after the "Invert the Transmit Clock Signal" section:
If the interface on the PA-8T synchronous serial port adapter is used to drive a dedicated T1 line that does not have B8ZS encoding, you must invert the data stream on the connecting CSU/DSU or on the interface. Be careful not to invert data on both the CSU/DSU and the interface as two data inversions will cancel each other out. To invert the data stream, complete the following task in interface configuration mode:
| Task | Command |
|---|---|
| Invert the data on an interface. | invert data |
Commands in the "Interface Commands" chapter of the Configuration Fundamentals Command Reference publication have been added and changed. Refer to the Cisco IOS Release 11.1 configuration guide and command reference publications for additional commands.
To configure compression for Link Access Procedure, Balanced (LAPB), Point-to-Point Protocol (PPP), and High-Level Data Link Control (HDLC) encapsulations, use the compress interface configuration command. On the Cisco 7000 series routers with RSP7000, Cisco 7500 series routers, and Cisco 7200 series routers, hardware compression on the compression service adapter (CSA) is supported for PPP links. To disable compression, use the no form of this command.
Syntax Description
| predictor | Specifies that a predictor (RAND) compression algorithm will be used on LAPB and PPP encapsulation. Compression is implemented in the software installed in the router's main processor. |
| stac | Specifies that a Stacker (LZS) compression algorithm will be used on LAPB, HDLC, and PPP encapsulation. For all platforms except Cisco 7200 series and platforms that support the VIP2, compression is implemented in the software installed in the router's main processor.
On the Cisco 7200 series and on VIP2s in all Cisco 7500 series and Cisco 7000 series routers with RSP7000, specifying the compress stac command with no options causes the router to use the fastest available compression method for PPP encapsulation only: · If the router contains a compression service adapter (CSA), compression is performed in the CSA hardware (hardware compression). · If the CSA is not available, compression is performed in the software installed on the VIP2 (distributed compression). · If the VIP2 is not available, compression is performed in the router's main processor (software compression). |
| distributed | (Optional) Specifies that compression is implemented in the software that is installed in a VIP2. If the VIP2 is not available, compression is performed in the router's main processor (software compression). |
| software | (Optional) Specifies that compression is implemented in the Cisco IOS software installed in the router's main processor. |
Default
Compression is disabled.
Command Mode
Interface configuration
Usage Guidelines
Using CSA hardware compression on the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers removes the compression and decompression responsibilities from the VIP2 or the main processor installed in the router. By using the compress stac command, the router determines the fastest compression method available on the router.
You can configure point-to-point software compression for all LAPB, PPP, and HDLC encapsulations. Compression reduces the size of frames via lossless data compression. HDLC encapsulations supports the Stacker compression algorithm. PPP and LAPB encapsulations support both predictor and Stacker compression algorithms.
When compression is performed in software installed in the router's main processor, it may significantly affect system performance. We recommend that you disable compression if the CPU load exceeds 40 percent. To display the CPU load, use the show process cpu EXEC command.
Compression requires that both ends of the serial link be configured to use compression.
If the majority of your traffic is already compressed files, we recommend that you not use compression. If the files are already compressed, the additional processing time spent in attempting unsuccessfully to compress them again will slow system performance.
Table 1 provides general guidelines for deciding which compression type to select.
| Situation | Compression Type to Use |
|---|---|
| The bottleneck is caused by the load on the router. | Predictor |
| The bottleneck is the result of line bandwidth or hardware compression on the CSA is available. | Stacker |
| Most files are already compressed. | None |
Software compression makes heavy demands on the router's processor. The maximum compressed serial line rate depends on the type of Cisco router you are using and which compression algorithm you specify. Table 2 shows a summary of the compressed serial line rates for software compression. The maximums shown in Table 2 apply to the "combined" serial compressed load on the router. For example, a Cisco 4000 series router could handle four 64-kbps lines using Stacker or one 256-kbps line. These maximums also assume there is very little processor load on the router aside from compression. Lower these numbers when the router is required to do other processor-intensive tasks.
| Router Family | Cisco 1000 | Cisco 3000 | Cisco 4000 | Cisco 4500 | Cisco 4700 | Cisco 7000 |
|---|---|---|---|---|---|---|
| Stacker (kbps) | 128 | 128 | 256 | 500 | T1 | 256 |
| Predictor (kbps) | 256 | 256 | 500 | T1 | 2xT1 | 500 |
Cisco recommends that you do not adjust the maximum transmission unit (MTU) for the serial interface and the LAPB maximum bits per frame (N1) parameter.
Examples
The following example enables hardware compression and PPP encapsulation on serial interface 3/1/0.
interface serial 3/1/0 encapsulate ppp compress stac
The following example enables predictor compression on serial interface 0 for a LAPB link:
interface serial 0 encapsulation lapb compress predictor
Related Commands
A dagger (†) indicates that the command is documented outside of this chapter.
encapsulation lapb
encapsulation ppp †
encapsulation x25
show compress
show processes †
To enable full-duplex mode on the FDDI full-duplex, single-mode port adapter (PA-F/FD-SM) and FDDI full-duplex, multimode port adapter (PA-F/FD-MM) on the Cisco 7000 series routers with RSP7000 and Cisco 7500 series routers, use the fddi full-duplex interface configuration command. FDDI full-duplex allows an FDDI ring with exactly two stations to transform the ring into a full-duplex, point-to-point topology. Use the no form of this command to disable this feature.
Syntax Description
This command has no arguments or keywords.
Default
Half-duplex mode
Command Mode
Interface configuration
Usage Guidelines
In order to operate in full-duplex mode, there must be only two stations on the ring, the two stations must be capable of operating in full-duplex mode, and both stations must complete a full-duplex autoconfiguration protocol. There is no FDDI token in full-duplex mode.
Full-duplex autoconfiguration protocol allows a station to dynamically and automatically operate in either half-duplex (or ring) or full-duplex mode, and ensures that the stations fall back to ring mode when a configuration change occurs, such as a third station joining the ring.
After booting up, the stations begin operation in ring mode. While the station performs the full-duplex autoconfiguration protocol, the station continues to provide data link services to its users. Under normal conditions, the transition between half-duplex mode and full-duplex mode is transparent to the data-link users. The data-link services provided by full-duplex mode are functionally the same as the services provided by half-duplex mode.
Use this command if your equipment on the other end is capable of full-duplex mode.
If you change the full-duplex configuration (for example from disabled to enabled) on supported interfaces, the interface resets.
If the interface does not support full-duplex, the following message is displayed, and no changes are made to the interface. To determine whether the interface supports full-duplex, use the show interfaces fddi command.
%FDDI-3-FDDIFAIL: Interface Fddi0/0/0, doesn't support, fddi full = 0x0
Example
The following example enables full-duplex mode on FDDI interface 0:
interface fddi 0/1/0 fddi full-duplex
Related Commands
interface fddi
show interfaces fddi
To invert the data stream, use the invert data interface configuration command. This command applies only to the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers. Use the no form of this command to disable this feature.
Syntax Description
This command has no arguments or keywords.
Default
Data in not inverted
Command Mode
Interface configuration
Usage Guidelines
If the interface on the PA-8T synchronous serial port adapter is used to drive a dedicated T1 line that does not have B8ZS encoding (a method to avoid 15 zeros), the data stream must be inverted (both TXD and RXD) either in the connecting CSU/DSU or the interface.
By inverting the HDLC data stream, the HDLC zero insertion algorithm becomes a ones insertion algorithm that satisfies the T1 requirements. Be careful not to invert data both on the interface and on the CSU/DSU as two data inversions will cancel each other out.
Example
The following example inverts data on serial interface 3/1/0:
interface serial 3/1/0 invert data
To invert the transmit clock signal, use the invert txclock interface configuration command. This command applies only to the Cisco 7000 series, Cisco 7200 series, and Cisco 7500 series routers. To return to the transmit clock signal to its initial state, use the no form of this command.
Syntax Description
This command has no arguments or keywords.
Default
Transmit clock signal is not inverted
Command Mode
Interface configuration
Usage Guidelines
Systems that use long cables or cables that are not transmitting the TxC signal (transmit echoed clock line, also known as TXCE or SCTE.clock) may experience high error rates when operating at the higher transmission speeds. For example, if a PA-8T synchronous serial port adapter is reporting a high number of error packets, a phase shift might be the problem. Inverting the clock may correct this shift.
When a PA-8T port adapter interface is DTE, the invert txclock command inverts the TxC signal it received from the remote DCE. When the PA-8T port adapter interface is DCE, this command changes the signal beck to its original phase.
Example
In the following example, the clock signal on serial interface 3/0 is inverted:
interface serial 3/0 invert txclock
To enable nonreturn-to-zero inverted (NRZI) line-coding format, use the nrzi-encoding interface configuration command. Use the no form of this command to disable this capability.
Syntax Description
| mark | (Optional) Specifies that NRZI mark encoding is required on the PA-8T synchronous serial port adapter on the Cisco 7000 series routers with RSP7000, Cisco 7200 series routers, and Cisco 7500 series routers. If mark is not specified, NRZI space encoding is used. |
Default
Disabled
Command Mode
Interface configuration
Usage Guidelines
All FSIP and PA-8T interface types support nonreturn-to-zero (NRZ) and nonreturn-to-zero inverted (NRZI) format. This is a line-coding format that is required for serial connections in some environments. NRZ encoding is most common. NRZI encoding is used primarily with EIA/TIA232 connections in IBM environments.
Examples
In the following example, serial interface 1 is configured for NRZI encoding:
interface serial 1 nrzi-encoding
In the following example, serial interface 3/1/0 is configured for NRZI mark encoding:
interface serial 3/1/0 nrzi-encoding mark
To display compression statistics, use the show compress EXEC command.
Syntax Description
This command has no arguments or keywords.
Command Mode
EXEC
Sample Displays
The following is sample output from the show compress command when software compression is used on the router:
Router# show compress Serial0 uncompressed bytes xmt/rcv 10710562/11376835 1 min avg ratio xmt/rcv 2.773/2.474 5 min avg ratio xmt/rcv 4.084/3.793 10 min avg ratio xmt/rcv 4.125/3.873 no bufs xmt 0 no bufs rcv 0 resets 0
Table 3 describes the fields shown in the display.
| Field | Description |
|---|---|
| Serial0 | Name and number of the interface. |
| uncompressed bytes xmt/rcv | Total number of uncompressed bytes sent and received. |
| 1 min avg ratio xmt/rcv
5 min avg ratio xmt/rcv 10 min avg ratio xmt/rcv |
Static compression ratio for bytes sent and received, averaged over 1, 5, and 10 minutes. |
| no bufs xmt | Number of times buffers were not available to compress data being sent. |
| no bufs rcv | Number of times buffers were not available to uncompress data being received. |
| resets | Number of resets (for example, line errors could cause resets). |
The following is sample output from the show compress command when hardware compression is enabled (that is, compression is implemented in the CSA hardware):
Router# show compress
Serial6/1
Hardware compression enabled
Compressed bytes sent: 402 bytes 0 Kbits/sec ratio: 4.092
Compressed bytes recv: 390 bytes 0 Kbits/sec ratio: 3.476
restarts:1
last clearing of counters: 1278 seconds
Table 4 describes the fields shown in the display. The information displayed by the show compress command is the same for hardware and distributed compression.
| Field | Description |
|---|---|
| Serial6/1 | Name and number of the interface. |
| Compressed bytes sent | Total number of compressed bytes sent including the kilobits per second. |
| Compressed bytes recv | Total number of compressed bytes received including the kilobits per second. |
| ratio | Compression ratio for bytes sent and received since the link last came up or since the counters were last cleared. |
| restarts | Number of times the compression process restarted or reset. |
| last clearing of counters | Duration since the last time the counters were cleared with the clear counters command. |
Related Command
Use the show interfaces fddi EXEC command to display information about the FDDI interface.
Syntax Description
| number | Port number on the selected interface. |
| accounting | (Optional) Displays the number of packets of each protocol type that have been sent through the interface. |
| slot | (Optional) On the Cisco 7000 series and 7500 series, slot location of the interface processor. |
| port-adapter | (Optional) On the Cisco 7000 series and 7500 series, specifies the ports on a VIP2 card. The value can be 0 or 1. |
| port | (Optional) On the Cisco 7000 series and 7500 series, port number on interface. |
Command Mode
EXEC
Sample Displays
The following is a sample partial display of FDDI-specific data from the show interfaces fddi command on a Cisco 7000:
Router> show interfaces fddi 3/0
Fddi3/0 is up, line protocol is up
Hardware is cxBus Fddi, address is 0000.0c02.adf1 (bia 0000.0c02.adf1)
Internet address is 131.108.33.14, subnet mask is 255.255.255.0
MTU 4470 bytes, BW 100000 Kbit, DLY 100 usec, rely 255/255, load 1/255
Encapsulation SNAP, loopback not set, keepalive not set
ARP type: SNAP, ARP Timeout 4:00:00
Phy-A state is active, neighbor is B, cmt signal bits 008/20C, status ILS
Phy-B state is active, neighbor is A, cmt signal bits 20C/008, status ILS
ECM is in, CFM is thru, RMT is ring_op
Token rotation 5000 usec, ring operational 21:32:34
Upstream neighbor 0000.0c02.ba83, downstream neighbor 0000.0c02.ba83
Last input 0:00:05, output 0:00:00, output hang never
Last clearing of "show interface" counters 0:59:10
Output queue 0/40, 0 drops; input queue 0/75, 0 drops
Five minute input rate 69000 bits/sec, 44 packets/sec
Five minute output rate 0 bits/sec, 1 packets/sec
113157 packets input, 21622582 bytes, 0 no buffer
Received 276 broadcasts, 0 runts, 0 giants
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
4740 packets output, 487346 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets, 0 restarts
0 transitions, 2 traces, 3 claims, 2 beacons
The following is a sample display of the show interfaces fddi command for the full-duplex FDDI port adapter on a Cisco 7500:
Router# show interfaces fddi 0/1/0
Fddi0/1/0 is up, line protocol is up
Hardware is cxBus FDDI, address is 0060.3e33.3608 (bia 0060.3e33.3608)
Internet address is 2.1.1.1/24
MTU 4470 bytes, BW 100000 Kbit, DLY 100 usec, rely 255/255, load 1/255
Encapsulation SNAP, loopback not set, keepalive not set
ARP type: SNAP, ARP Timeout 04:00:00
FDX supported, FDX enabled, FDX state is operation
Phy-A state is maintenance, neighbor is Unknown, status HLS
Phy-B state is active, neighbor is A, status SILS
ECM is in, CFM is c_wrap_b, RMT is ring_op,
Requested token rotation 5000 usec, negotiated 4997 usec
Configured tvx is 2500 usec
LER for PortA = 0A, LER for PortB = 0A ring operational 00:02:45
Upstream neighbor 0060.3e73.4600, downstream neighbor 0060.3e73.4600
Last input 00:00:12, output 00:00:13, output hang never
Last clearing of "show interface" counters never
Queueing strategy: fifo
Output queue 0/40, 0 drops; input queue 0/75, 0 drops
5 minute input rate 0 bits/sec, 0 packets/sec
5 minute output rate 0 bits/sec, 0 packets/sec
62 packets input, 6024 bytes, 0 no buffer
Received 18 broadcasts, 0 runts, 0 giants
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
71 packets output, 4961 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 output buffer failures, 0 output buffers swapped out
3 transitions, 0 traces, 100 claims, 0 beacon
Table 5 describes the show interfaces fddi display fields.
| Field | Description |
| Fddi is {up | down}...is administratively down | Gives the interface processor unit number and tells whether the interface hardware is currently active and can transmit and receive or if it has been taken down by an administrator. |
| line protocol is {up | down} | Indicates whether the software processes that handle the line protocol consider the interface usable. |
| Hardware | Provides the hardware type, followed by the hardware address. |
| Internet address | IP address, followed by subnet mask. |
| MTU | Maximum Transmission Unit of the interface. |
| BW | Bandwidth of the interface in kilobits per second. |
| DLY | Delay of the interface in microseconds. |
| rely | Reliability of the interface as a fraction of 255 (255/255 is 100% reliability), calculated as an exponential average over 5 minutes. |
| load | Load on the interface as a fraction of 255 (255/255 is completely saturated), calculated as an exponential average over 5 minutes. |
| Encapsulation | Encapsulation method assigned to interface. |
| loopback | Indicates whether or not loopback is set. |
| keepalive | Indicates whether or not keepalives are set. |
| ARP type | Type of Address Resolution Protocol assigned. |
| FDX | Displays full-duplex information. Values are: not supported or supported. When the value is supported, the display indicates whether full-duplex is enabled or disabled. When enabled, the state of the FDX negotiation process is displayed. The negotiation states only relate to the full-duplex negotiation process. You must also ensure that the interface is up and working by looking at other fields in the show interfaces fddi command such as line protocol and RMT. Negotiation states are:
|
| Phy-{A | B} | Lists the state the Physical A or Physical B connection is in; one of the following: off, active, trace, connect, next, signal, join, verify, or break. |
| neighbor | State of the neighbor:
|
| cmt signal bits | Shows the transmitted/received CMT bits. The transmitted bits are 0x008 for a Physical A type and 0x20C for Physical B type. The number after the slash (/) is the received signal bits. If the connection is not active, the received bits are zero (0); see the line beginning Phy-B in the display. |
| status | Status value displayed is the actual status on the fiber. The FDDI standard defines the following values:
|
| ECM is... | ECM is the SMT entity coordination management, which overlooks the operation of CFM and PCM. The ECM state can be one of the following:
|
| CFM is... | Contains information about the current state of the MAC connection. The Configuration Management state can be one of the following:
|
| RMT is... | RMT (Ring Management) is the SMT MAC-related state machine. The RMT state can be one of the following:
|
| token rotation | Token rotation value is the default or configured rotation value as determined by the fddi token-rotation-time command. This value is used by all stations on the ring. The default is 5000 microseconds. |
| negotiated | Actual (negotiated) target token rotation time. |
| ring operational | When the ring is operational, the displayed value will be the negotiated token rotation time of all stations on the ring. Operational times are displayed by the number of hours:minutes:seconds the ring has been up. If the ring is not operational, the message "ring not operational" is displayed. |
| Configured tvx | Transmission timer. |
| LER | Link error rate. |
| Upstream | downstream neighbor | Displays the canonical MAC address of outgoing upstream and downstream neighbors. If the address is unknown, the value will be the FDDI unknown address (0x00 00 f8 00 00 00). |
| Last input | Number of hours, minutes, and seconds since the last packet was successfully received by an interface. Useful for knowing when a dead interface failed. |
| output | Number of hours, minutes, and seconds since the last packet was successfully transmitted by an interface. |
| output hang | Number of hours, minutes, and seconds (or never) since the interface was last reset because of a transmission that took too long. When the number of hours in any of the "last" fields exceeds 24 hours, the number of days and hours is printed. If that field overflows, asterisks are printed. |
| Last clearing | Time at which the counters that measure cumulative statistics (such as number of bytes transmitted and received) shown in this report were last reset to zero. Note that variables that might affect routing (for example, load and reliability) are not cleared when the counters are cleared.
*** indicates the elapsed time is too large to be displayed. 0:00:00 indicates the counters were cleared more than 231ms (and less than 232ms) ago. |
| Queueing strategy | First-in, first-out queuing strategy (other queueing strategies you might see are priority-list, custom-list, and weighted fair). |
| Output queue, input queue, drops | Number of packets in output and input queues. Each number is followed by a slash, the maximum size of the queue, and the number of packets dropped due to a full queue. |
| Five-minute input rate
Five-minute output rate |
Average number of bits and packets transmitted per second in the last 5 minutes.
The five-minute input and output rates should be used only as an approximation of traffic per second during a given 5-minute period. These rates are exponentially weighted averages with a time constant of 5 minutes. A period of four time constants must pass before the average will be within two percent of the instantaneous rate of a uniform stream of traffic over that period. |
| packets input | Total number of error-free packets received by the system. |
| bytes | Total number of bytes, including data and MAC encapsulation, in the error free packets received by the system. |
| no buffer | Number of received packets discarded because there was no buffer space in the main system. Compare with ignored count. Broadcast storms on Ethernets and bursts of noise on serial lines are often responsible for no input buffer events. |
| broadcasts | Total number of broadcast or multicast packets received by the interface. |
| runts | Number of packets that are discarded because they are smaller than the medium's minimum packet size. |
| giants | Number of packets that are discarded because they exceed the medium's maximum packet size. |
| CRC | Cyclic redundancy checksum generated by the originating LAN station or far-end device does not match the checksum calculated from the data received. On a LAN, this usually indicates noise or transmission problems on the LAN interface or the LAN bus itself. A high number of CRCs is usually the result of collisions or a station transmitting bad data. |
| frame | Number of packets received incorrectly that have a CRC error and a noninteger number of octets. On a LAN, this is usually the result of collisions or a malfunctioning Ethernet device. On an FDDI LAN, this also may be the result of a failing fiber (cracks) or a hardware malfunction. |
| overrun | Number of times the serial receiver hardware was unable to hand received data to a hardware buffer because the input rate exceeded the receiver's ability to handle the data. |
| ignored | Number of received packets ignored by the interface because the interface hardware ran low on internal buffers. These buffers are different from the system buffers mentioned previously in the buffer description. Broadcast storms and bursts of noise can cause the ignored count to be increased. |
| packets output | Total number of messages transmitted by the system. |
| bytes | Total number of bytes, including data and MAC encapsulation, transmitted by the system. |
| underruns | Number of transmit aborts (when the router cannot feed the transmitter fast enough). |
| output errors | Sum of all errors that prevented the final transmission of datagrams out of the interface being examined. Note that this may not balance with the sum of the enumerated output errors, because some datagrams may have more than one error, and others may have errors that do not fall into any of the specifically tabulated categories. |
| collisions | Because an FDDI ring cannot have collisions, this statistic is always zero. |
| interface resets | Number of times an interface has been reset. The interface may be reset by the administrator or automatically when an internal error occurs. |
| restarts | Should always be zero for FDDI interfaces. |
| output buffer failures | Number of no resource errors received on the output. |
| output buffers swapped out | Number of packets swapped to DRAM. |
| transitions | The number of times the ring made a transition from ring operational to ring nonoperational, or vice versa. A large number of transitions indicates a problem with the ring or the interface. |
| traces | Trace count applies to both the FCI, FCIT, and FIP. Indicates the number of times this interface started a trace. |
| claims | Pertains to FCIT and FIP only. Indicates the number of times this interface has been in claim state. |
| beacons | Pertains to FCIT and FIP only. Indicates the number of times the interface has been in beacon state. |
The following is an example that includes the accounting option. When you use the accounting option, only the accounting statistics are displayed.
Router> show interfaces fddi 3/0 accounting
Fddi3/0
Protocol Pkts In Chars In Pkts Out Chars Out
IP 7344 4787842 1803 1535774
Appletalk 33345 4797459 12781 1089695
DEC MOP 0 0 127 9779
ARP 7 420 39 2340
Table 6 describes the show interfaces fddi display fields.
| Field | Description |
| Protocol | Protocol that is operating on the interface. |
| Pkts In | Number of packets received for that protocol. |
| Chars In | Number of characters received for that protocol. |
| Pkts Out | Number of packets transmitted for that protocol. |
| Chars Out | Number of characters transmitted for that protocol. |
Cisco Connection Online (CCO), formerly Cisco Information Online (CIO), is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional content and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously---a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
For a copy of CCO's Frequently Asked Questions (FAQ), contact ccohelp@cisco.com. For additional information, contact ccoteam@cisco.com.
Cisco Connection Documentation
The complete caveats against this release are available on the Cisco Connection Documentation, Enterprise Series CD---formerly UniverCD---which is the Cisco library of product information on CD-ROM. On the CD, access the Cisco IOS 11.1 caveats in the Cisco IOS Release 11.1 database.
The CD is updated and shipped monthly so it might be more current than printed documentation. To order the Cisco Connection Documentation, Enterprise Series CD, contact your local sales representative or call Customer Service. The CD is available both as a single CD and as an annual subscription.You can also access Cisco technical documentation on the World Wide Web URL http://www.cisco.com.
|
Copyright 1988-1996 © Cisco Systems Inc.
