December 29, 1997
These release notes describe the new features and significant software components for Cisco IOS Release 11.3 for Cisco 1600 series routers. For detailed information about the features and caveats in these release notes, refer to the Release Notes for Cisco IOS Release 11.3 publication, which contains features and caveats for all 11.3 platforms. This publication is available on the Documentation CD-ROM and on Cisco Connection Online (CCO), which are described in the section "Online Navigation."
These release notes discuss the following topics:
To determine which Cisco IOS software release is running on your Cisco 1600 series router, log on to the router and enter the show version User EXEC command, as shown below:
router> show version Cisco Internetwork Operating System Software IOS (tm) 1600 Software (C1600-Y-L), Version 11.3(1), RELEASE SOFTWARE Copyright (c) 1986-1997 by cisco Systems, Inc. Compiled Mon 01-Dec-97 20:30 by richard Image text-base: 0x0801FCFC, data-base: 0x02005000 ROM: System Bootstrap, Version 11.1(10)AA, EARLY DEPLOYMENT RELEASE SOFTWARE (fc1) ROM: 1600 Software (C1600-BOOT-R), Version 11.1(10)AA, EARLY DEPLOYMENT RELEASE SOFTWARE (fc1) router uptime is 2 hours, 41 minutes System restarted by reload System image file is "flash:testimage.tga2d", booted via flash cisco 1601 (68360) processor (revision C) with 1536K/512K bytes of memory. Processor board ID 06037310, with hardware revision 00000000 Bridging software. X.25 software, Version 3.0.0. 1 Ethernet/IEEE 802.3 interface(s) 2 serial(sync/async) network interface(s) System/IO memory with parity disabled 8K bytes of non-volatile configuration memory. 8192K bytes of processor board PCMCIA flash (Read ONLY) Configuration register is 0x0
The Cisco 1600 series of access routers deliver the next-generation set of features and benefits for small-office Internet and intranet access: WAN flexibility, end-to-end security, end-to-end quality of service, ease of use, deployment, and management. Cisco 1600 series routers connect small offices with Ethernet LANs to the public Internet and to a company's internal intranet or corporate LAN through several WAN connections such as ISDN, asynchronous serial, and synchronous serial. Cisco 1600 series routers include the following models: the Cisco 1601, Cisco 1602, Cisco 1603, and Cisco 1604.
All Cisco 1600 series models include one Ethernet port, one built-in WAN port, and one WAN interface card expansion slot for additional connectivity and flexibility. The Cisco 1601 includes a built-in serial WAN port; the Cisco 1602 has an onboard 56-kbps four-wire channel service unit/data service unit (CSU/DSU); the Cisco 1603 has an ISDN BRI S/T port; and the Cisco 1604 includes an ISDN BRI U interface with a built-in NT1 device.
The following are 1-port WAN interface cards supported by the Cisco 1600 series routers:
The Cisco IOS software documentation is divided into nine modules and two master indexes. There are also four supporting documents.
Each module consists of two books: a configuration guide and a corresponding command reference. Chapters in a configuration guide describe protocols, configuration tasks, and Cisco IOS software functionality and contain comprehensive configuration examples. Chapters in a command reference provide complete command syntax information. Each configuration guide can be used in conjunction with its corresponding command reference.
Two master indexes provide indexing information for the Cisco IOS software documentation set: an index for the configuration guides and an index for the command references. In addition, individual books contain a book-specific index.
The Cisco IOS documentation set consists of the following books and chapter topics:
| Books | Chapter Topics |
|---|---|
| · Configuration Fundamentals Configuration Guide
· Configuration Fundamentals Command Reference | Configuration Fundamentals Overview
Cisco IOS User Interfaces File Management Interface Configuration System Management |
| · Network Protocols Configuration Guide, Part 1
· Network Protocols Command Reference, Part 1 | IP Addressing
IP Services IP Routing Protocols |
| · Network Protocols Configuration Guide, Part 2
· Network Protocols Command Reference, Part 2 | AppleTalk
Novell IPX |
| · Network Protocols Configuration Guide, Part 3
· Network Protocols Command Reference, Part 3 | Apollo Domain
Banyan VINES DECnet ISO CLNS XNS |
| · Wide-Area Networking Configuration Guide
· Wide-Area Networking Command Reference | ATM
Frame Relay SMDS X.25 and LAPB |
| · Security Configuration Guide
· Security Command Reference | Terminal Access Security
Network Access Security Accounting and Billing Filtering Traffic Preventing Fraudulent Route Updates Network Data Encryption |
| · Dial Solutions Configuration Guide
· Dial Solutions Command Reference | Dial Business Solutions and Examples
Dial-In Port Setup DDR and Dial Backup Remote Node and Terminal Service Cost-Control and Large-Scale Dial Solutions VPDN |
| · Cisco IOS Switching Services Configuration Guide
· Cisco IOS Switching Services Command Reference | Switching Paths for IP Networks
· Fast Switching · Autonomous Switching · NetFlow Switching · Optimum Switching Virtual LAN (VLAN) Switching and Routing · Inter-Switch Link Protocol Encapsulation · IEEE 802.10 Encapsulation · LAN Emulation |
| · Bridging and IBM Networking Configuration Guide
· Bridging and IBM Networking Command Reference | Transparent Bridging
Source-Route Bridging Remote Source-Route Bridging DLSw+ STUN and BSTUN LLC2 and SDLC IBM Network Media Translation DSPU and SNA Service Point SNA Frame Relay Access Support APPN NCIA Client/Server Topologies IBM Channel Attach |
| · Cisco IOS Software Command Summary
· Dial Solutions Quick Configuration Guide · System Error Messages · Debug Command Reference |
The Cisco IOS software documentation set is available as printed manuals or electronic documents. You can access the electronic documents either on the Cisco Documentation CD-ROM or at Cisco Connection Online (CCO) on the World Wide Web:
New online navigation enhancements for Release 11.3 include:
For additional information about the Documentation CD-ROM and CCO, refer to the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of these release notes.
Release 11.3 supports features in the following categories:
Detailed descriptions of the features are available on the Documentation CD-ROM and on CCO:
The Cisco IOS software is packaged into "feature sets" (also called "software images"). There are many different feature sets available, and each feature set contains a specific subset of Cisco IOS features. Table 1 provides a matrix of the new feature set organization and shows which feature sets are available on the Cisco 1600 series routers. These feature sets only apply to Cisco IOS Release 11.3.
The tables use the following conventions to identify feature sets:
Cisco IOS images with strong encryption (including, but not limited to, 56-bit DES) are subject to U.S. government export controls and have a limited distribution. Images to be installed outside the U.S. require an export license. Customer orders may be denied or subject to delay due to U.S. government regulations. Contact your sales representative or distributor for more information, or send e-mail to export@cisco.com.
| Feature Set | Cisco 16001 Platform |
|---|---|
| IP | Yes |
| IP Plus | Yes |
| IP Plus 40 | Yes |
| IP Plus 56 | Yes |
| IP 40 | No |
| IP 56 | No |
| IP/IPX | Yes |
| IP/IPX Plus | Yes |
| IP/IPX/AT | No |
| IP/IPX/AT Plus | No |
| IP/IPX/AT Plus 40 | No |
| IP/IPX/AT Plus 56 | No |
| IP/ASYNC | No |
| IP/IPX/ASYNC | No |
| IP/OSPF/PIM | No |
| IP/IPX/AT/IBM | Yes |
| IP/IPX/AT/IBM Plus | Yes |
| IP/IPX/AT/IBM Plus 40 | Yes |
| IP/IPX/AT/IBM Plus 56 | Yes |
| ISDN | No |
| Desktop | No |
| Desktop Plus | No |
| Desktop IBM | No |
| Desktop IBM 40 | No |
| Desktop IBM 56 | No |
| ATM Cable Interface Processor | No |
| IP/IPX/AT/DEC | No |
| IP/IPX/AT/DEC Plus | No |
| Enterprise | No |
| Enterprise Plus | No |
| Enterprise Plus 40 | No |
| Enterprise 40 | No |
| Enterprise Plus 56 | No |
| Enterprise 56 | No |
| Enterprise APPN | No |
| Enterprise APPN Plus | No |
| Enterprise APPN Plus 40 | No |
| Enterprise APPN Plus 56 | No |
| Enterprise APPN 40 | No |
| Enterprise APPN 56 | No |
| Remote Access Server | No |
| FRAD | No |
| LAN FRAD | No |
| Netflow Layer 3 Switching | No |
To determine what features are available with each feature set, see Table 2. The table summarizes what features you can use when running a specific feature set on the Cisco 1600 series for Cisco IOS Release 11.3. The feature set table uses the following symbol conventions to identify features:
| Feature Set | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Feature | IP | IP Plus | IP Plus 40 | IP Plus 56 | IP/IPX | IP/IPX Plus | IP/IPX/ AT/IBM | IP/IPX/ AT/IBM Plus | IP/IPX/ AT/IBM Plus 40 | IP/IPX/ AT/IBM PLUS 56 |
| IBM Support | ||||||||||
| APPN High Performance Routing | No | No | No | No | No | No | No | No | No | No |
| APPN MIB Enchancements | No | No | No | No | No | No | No | No | No | No |
| APPN over Ethernet LAN Emulation | No | No | No | No | No | No | No | No | No | No |
| APPN Scalability Enhancements | No | No | No | No | No | No | No | No | No | No |
Bisync Enhancements, includes:
|
No | No | No | No | No | No | Yes | Yes | Yes | Yes |
| Cisco MultiPath Channel (CMPC) | No | No | No | No | No | No | No | No | No | No |
DLSw+ Enhancements, includes:
|
No | No | No | No | No | No | No | No | No | No |
FRAS Enhancements, includes:
|
No | No | No | No | No | No | No | No | No | No |
| SRB over FDDI on Cisco 4000-M, 4500-M, and 4700-M Routers | No | No | No | No | No | No | No | No | No | No |
| TN3270 LU Nailing | No | No | No | No | No | No | No | No | No | No |
| TN3270 Server Enhancements | No | No | No | No | No | No | No | No | No | No |
| Token Ring LANE | No | No | No | No | No | No | No | No | No | No |
| Tunneling of Asynchronous Security Protocols | No | No | No | No | No | No | No | No | No | No |
| Internet | ||||||||||
| DRP Server Agent | No | No | No | No | No | No | No | No | No | No |
| IP Routing | ||||||||||
| Easy IP (Phase 1) | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Hot Standby Router Protocol (HSRP) over ISL in Virtual LAN Configurations | No | No | No | No | No | No | No | No | No | No |
| IP Enhanced IGRP Route Authentication | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
TCP Enhancements, includes:
|
No | No | No | No | No | No | No | No | No | No |
| LAN Support | ||||||||||
| AppleTalk Access List Enhancements | No | No | No | No | No | No | No | Yes | Yes | Yes |
| DECnet Accounting | No | No | No | No | No | No | No | No | No | No |
| IPX Named Access Lists | No | No | No | No | Yes | Yes | Yes | Yes | Yes | Yes |
| IPX SAP-after-RIP | No | No | No | No | Yes | Yes | Yes | Yes | Yes | Yes |
| NLSP Enhancements | No | No | No | No | No | Yes | No | Yes | Yes | Yes |
| NLSP Multicast Support | No | No | No | No | No | Yes | No | Yes | Yes | Yes |
| Management | ||||||||||
| Cisco Call History MIB Command Line Interface | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Cisco IOS Internationalization | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Entity MIB, Phase 1 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| SNMPv2C | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Virtual Profiles | No | No | No | No | No | No | No | No | No | No |
| Multimedia | ||||||||||
| IP Multicast Load Splitting across Equal-Cost Paths | No | Yes | Yes | Yes | No | Yes | No | Yes | Yes | Yes |
| IP Multicast over ATM Point-to-Multipoint Virtual Circuits | No | No | No | No | No | No | No | No | No | No |
| IP Multicast over Token Ring LANs | No | No | No | No | No | No | No | No | No | No |
| Stub IP Multicast Routing | No | Yes | Yes | Yes | No | Yes | No | Yes | Yes | Yes |
| Quality of Service | ||||||||||
| RTP Header Compression | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Security | ||||||||||
| Double Authentication | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Encrypted Kerberized Telnet | No | No | No | No | No | No | No | No | No | No |
| HTTP Security | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Per-User Configuration | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Reflexive Access Lists | No | No | No | No | No | No | No | No | No | No |
| TCP Intercept | No | No | No | No | No | No | No | No | No | No |
| Vendor-Proprietary RADIUS Attributes | No | No | No | No | No | No | No | No | No | No |
| Switching | ||||||||||
| AppleTalk Routing over ISL and IEEE 802.10 in Virtual LANs | No | No | No | No | No | No | No | No | No | No |
| CLNS and DECnet Fast Switching over PPP | No | No | No | No | No | No | No | No | No | No |
DECnet/Vines/XNS over ISL, includes:
|
No | No | No | No | No | No | No | No | No | No |
| Fast-Switched Policy Routing | No | No | No | No | No | No | No | No | No | No |
| IPX Routing over ISL Virtual LANs | No | No | No | No | No | No | No | No | No | No |
| VIP Distributed Switching Support for IP Encapsulated in ISL | No | No | No | No | No | No | No | No | No | No |
| Terminal Services | ||||||||||
| Virtual Interface Template Service | No | No | No | No | No | No | No | No | No | No |
| Virtual Templates for Protocol Translation | No | No | No | No | No | No | No | No | No | No |
| WAN Optimization | ||||||||||
| ATM MIB Enhancements | No | No | No | No | No | No | No | No | No | No |
| PAD Enhancements | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| PAD Subaddressing | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| WAN Services | ||||||||||
| Bandwidth Allocation Control Protocol | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Enhanced Local Management Interface (ELMI) | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay Enhancements | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay MIB Extensions | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Frame Relay Router ForeSight | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| ISDN Advice of Charge | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| ISDN Caller ID Callback | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| ISDN NFAS | No | No | No | No | No | No | No | No | No | No |
| LANE Per-subinterface Debug Messages | No | No | No | No | No | No | No | No | No | No |
| Layer 2 Forwarding--Fast Switching | No | No | No | No | No | No | No | No | No | No |
| Leased Line ISDN at 128 kbps | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Multilink PPP Interleaving and Fair-Queuing Support | No | No | No | No | No | No | No | No | No | No |
| PPP over ATM | No | No | No | No | No | No | No | No | No | No |
| Telnet Extensions for Dialout | No | No | No | No | No | No | No | No | No | No |
| VPDN Tunnel Lookup Based on Dialed Number Information | No | No | No | No | No | No | No | No | No | No |
| X.25 Enhancements | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| X.25 on ISDN | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| X.25 Switching between PVCs and SVCs | No | No | No | No | No | No | No | No | No | No |
| X.28 Emulation | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
If you are upgrading to Cisco IOS Release 11.3 from an earlier Cisco IOS software release, you should save your current configuration file before configuring your access server with the Cisco IOS Release 11.3 software. An unrecoverable error could occur during download or configuration.
For instructions on downloading a current Cisco IOS release from the CCO Trivial File Transfer Protocol (TFTP) server, go to the following URL. This URL is subject to change without notice.
http://www.cisco.com/kobayashi/sw-center
The Software Center window is displayed.
Step 1 Click Cisco IOS Software. The Cisco IOS Software window is displayed.
Step 2 Click Cisco IOS 11.3. The Cisco 11.3 Software Upgrade Planner window is displayed.
Step 3 Click Download Cisco IOS 11.3 Software. The Software Checklist window is displayed.
Step 4 Select the appropriate information in each section of the Software Checklist window.
Step 5 Hardware
Step 6 Release
Step 7 Software and hardware release
Step 8 Click Execute. The software release is downloaded to your desktop computer.
Step 9 Transfer the software release to a local TFTP server on your network, using a terminal emulation application, such as TCP Connect.
Step 10 Log on to your router. Copy the software release from your TFTP server to your router, using the copy tftp command.
Table 3 describes the memory requirements for the Cisco 1600 series platform feature set supported by Cisco IOS Release 11.3. For Cisco routers to take advantage of the Release 11.3 features, you must upgrade the code or main system memory. Some platforms have specific chip or architecture requirements that affect what can be upgraded and in what increments.
| Platform/Feature Set | Minimum Required Code Memory | Required Main Memory | Release 11.3 Runs from |
|---|---|---|---|
| IP | 4 MB Flash | 2 MB DRAM | Flash |
| IP Plus | 6 MB Flash | 4 MB DRAM | Flash |
| IP Plus 40 | 6 MB Flash | 4 MB DRAM | Flash |
| IP Plus 56 | 6 MB Flash | 4 MB DRAM | Flash |
| IP/IPX | 6 MB Flash | 2 MB DRAM | Flash |
| IP/IPX Plus | 6 MB Flash | 4 MB DRAM | Flash |
| IP/IPX/AT/IBM | 8 MB Flash | 4 MB DRAM | Flash |
| IP/IPX/AT/IBM Plus | 8 MB Flash | 6 MB DRAM | Flash |
| IP/IPX/AT/IBM Plus 40 | 8 MB Flash | 6 MB DRAM | Flash |
| IP/IPX/AT/IBM Plus 56 | 8 MB Flash | 6 MB DRAM | Flash |
Possibly unexpected behavior in Cisco IOS Release 11.3 exists in the following areas:
A complete list of the caveats, including descriptions and possible workarounds, is available on the Documentation CD-ROM and on CCO:
Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.
Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more up to date than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or http://www-europe.cisco.com.
|
|
